BOX PC APQ IPC200-Q870SA2
Remote management
Condition monitoring
Remote operation and maintenance
Safety Control
CONTACT US|
Model |
IPC200-Q870SA2 |
|
|
Processor System |
CPU | Intel® Core Ultra (Series 2)Desktop CPU |
|
|
TDP | 125W |
|
|
Socket | LGA1851 |
|
|
Chipset | Q870 |
|
|
BIOS | AMI UEFI BIOS |
|
Memory |
Socket | 4 * U-DIMM slot，Dual Channel DDR5-5600 MT/s |
|
|
Capacity | 192GB, Single Max 48GB |
|
Ethernet |
Controller | 1 * Intel i210-AT Chip
1 * Intel i219-V Chip |
|
Storage |
SATA | 4 * SATA 3.0 Connector |
|
|
M.2 | 1 * M.2 Key-M slot（PCIe Gen4 x4 + SATA 3.0 signal，NVMe/SATA SSD Auto，2242/2280） |
|
Expansion Slots |
PCIe | 1 * PCIe x16 slot
1 * PCIe x16 slot 4 * PCIe x4 slot |
|
|
PCI | 1 * PCI slot |
|
|
M.2 | 1 * M.2 Key-E slot（PCIe Gen 4 x1 + USB 2.0，2230） |
|
Rear I/O |
Ethernet | 2 * RJ45 |
|
|
USB | 2 * USB 10Gbps Type-A
4 * USB 5Gbps Type-A 2 * USB 2.0 Type-A |
|
|
Display | 1 * DP：max resolution up to 4096*2160 @ 60Hz 1 * HDMI：max resolution up to 4096*2160 @ 60Hz 1 * VGA：max resolution up to 1920*1200 @ 60Hz |
|
|
Audio | 3 * 3.5mm Jack（Line-out + Line-in + MIC） |
|
|
Serial | 1 * RS232 DB9/M（COM1） |
|
Front I/O |
USB | 2 * USB 2.0 Type-A |
|
|
Button | 1 *Power Button |
|
|
LED | 1 * Power status LED
1 * Hard drive status LED |
|
Internal Interfaces |
USB | 2 * USB 2.0(Type-A)
1 * USB 2.0 |
|
|
COM | 3 * RS232（COM2/5/6）
1 * RS232/RS485/RS422（COM3） 1 * RS232/RS485（COM4） |
|
|
Audio | 1 * Front Audio（Line-Out + MIC） |
|
|
IO | 1 × 8-channel digital input/output header (default: 4 inputs, 4 outputs) |
|
|
SATA | 4 * SATA 3.0 Connector |
|
|
FAN | 2 * SYS FAN (Header)
1 * CPU FAN (Header) |
|
Power Supply |
Type | 2U |
|
|
Power Input Voltage | AC power supply, voltage and frequency shall be based on the ATX power supply provided |
|
|
RTC Battery | CR2032 Coin Cell |
|
OS Support |
Windows | Win 10/11 |
|
|
Linux | Linux |
|
Platform |
TPM | fTPM，optional dTPM2.0 |
|
Watchdog |
Output | System Reset |
|
|
Interval | Programmable 1 ~ 255 sec |
|
Mechanical |
Enclosure Material | SGCC |
|
|
Dimensions | 482.6mm (L) * 475.7mm (W) * 88.1mm (H) |
|
|
Mounting | Shelf mounted installation |
|
Environment |
Heat Dissipation System | PWM fan cooling |
| Operating Temperature | 0 ~ 50℃ | |
| Storage Temperature | -20 ~ 70℃ | |
| Relative Humidity | 10 ~ 90%(non-condensing) | |
