The APQ 4U rackmount industrial PC IPC400-Z390SA2 supports Intel® 6th / 8th / 9th Gen Core™ / Pentium® / Celeron® desktop processors, featuring a standard 19-inch 4U rack-mounted chassis with fully molded structural design. It accommodates standard ATX motherboards and 4U power supplies, with up to 7 expansion slots. The front-mounted system fans allow tool-free maintenance, while PCIe expansion cards utilize a tool-free mounting bracket design for enhanced shock resistance. Storage-wise, it offers up to 8 3.5-inch hard drive bays and 2 5.25-inch optical drive bays. The front panel includes USB ports, power switch, and status indicators for easy system maintenance, along with non-live opening alarm and front door lock functions to prevent unauthorized access.
In summary, the APQ 4U rackmount industrial PC IPC400-Z390SA2 is a high-performance, reliable, and secure computing product specifically designed for industrial applications, making it an ideal choice for your industrial automation system.
|
Model |
IPC400-Z390SA2 |
|
|
Processor System |
CPU |
Supports Intel® 6th / 8th / 9th Gen Core™ / Pentium® / Celeron® desktop processors |
|
TDP |
Six-core 95 W CPUs supported (8-core 65 W / 95 W processors are not supported) |
|
|
Socket |
LGA1151 |
|
|
Chipset |
Z390 |
|
|
BIOS |
AMI UEFI BIOS |
|
|
Memory |
Socket |
2 × U-DIMM slots, dual-channel DDR4-2400 / 2666 MHz support |
|
Capacity |
Maximum 64 GB, up to 32 GB per DIMM |
|
|
Ethernet |
Chipset |
· 1 × Intel® i210-AT Gigabit Ethernet controller · 1 × Intel® i219-V/LM Gigabit Ethernet controller |
|
Storage |
SATA |
4 × SATA 3.0 ports |
|
M.2 |
1 × mSATA slot (SATA 3.0 signal, mSATA SSD) |
|
|
Expansion Slots |
PCIe |
· 1 × PCIe x16 slot (PCIe Gen 3 x16 signal, slot 1) · 2 × PCIe x4 slots (PCIe Gen 3 x4 signal, slots 2 and 3) |
|
PCI |
4 × PCI slots (slots 4, 5, 6, and 7) |
|
|
Mini PCIe |
1 × Mini PCIe slot (PCIe Gen 3 x1 + USB 2.0 signal, with 1 × SIM card slot) |
|
|
Rear I/O |
Ethernet |
2 × RJ45 ports |
|
USB |
· 4 × USB 5Gbps Type-A ports · 2 × USB 2.0 Type-A ports |
|
|
PS/2 |
1 × PS/2 combo port (keyboard and mouse) |
|
|
Display |
· 1 × DVI-D port: up to 1920 × 1200 @ 60 Hz · 1 × HDMI port: up to 4096 × 2160 @ 30 Hz · 1 × VGA port: up to 1920 × 1200 @ 60 Hz |
|
|
Audio |
3 × 3.5 mm audio jacks (Line-out / Line-in / MIC) |
|
|
Serial |
1 × RS232 DB9 male connector (COM1) |
|
|
Front I/O |
USB |
2 × USB 2.0 Type-A ports |
|
Button |
1 × Power button |
|
|
LED |
· 1 × Power status LED · 1 × HDD status LED |
|
|
Internal I/O |
USB |
· 1 × Vertical USB 2.0 Type-A port · 2 × USB 5Gbps pin headers · 2 × USB 2.0 pin headers |
|
Serial |
· 3 × RS232 pin headers (COM2 / COM5 / COM6) · 2 × RS232 / RS485 pin headers (COM3 / COM4, selectable via jumper) |
|
|
Audio |
1 × Front audio pin header (Line-out + MIC) |
|
|
GPIO |
1 × 8-channel digital I/O pin header (default 4 DI + 4 DO; logic-level only, no load-driving capability) |
|
|
SATA |
4 × SATA 3.0 ports |
|
|
Fan |
· 2 × system fan headers · 1 × CPU fan header |
|
|
Power Supply |
Type |
ATX |
|
Power Input Voltage |
Voltage range depends on selected power supply |
|
|
RTC Battery |
CR2032 coin-cell battery |
|
|
OS Support |
Windows |
6 Gen CPU：Win 7/10/11 8/9 Gen CPU：Win 10/11 |
|
Linux |
Linux |
|
|
Trusted Platform |
TPM |
Default fTPM, optional dTPM 2.0 |
|
Watchdog |
Output |
Syetem Reset |
|
Intervel |
1 ~ 255 seconds |
|
|
Mechanical |
Enclosure Material |
Galvanized steel |
|
Dimensions |
482.6mm(W) * 464.5mm(D) * 177mm(H) |
|
|
Mounting |
Rackmount |
|
|
Environment |
Heat Dissipation System |
Smart fan cooling |
|
Operating Temperature |
0 ~ 50℃ |
|
|
Storage Temperature |
-20 ~ 70℃ |
|
|
Relative Humidity |
10 ~ 90%，non-condensing |
|
