Ultra-Thin Panel APQ ITD Series
Remote management
Condition monitoring
Remote operation and maintenance
Safety Control
CONTACT USProduct Specification
| General | Touch | ||
| l I/0 Interface | DP, HDMI, VGA, USB | l Touch Type | Projected Capacitive Multi-touch Screen |
| l Power | 2-pin 3.8mm (12V) | l Control Signal | USB |
| l Structure | Front frame: Aluminum alloy, Rear cover: SGCC | l Touch Method | Finger / Capacitive Touch Pen |
| l Mounting | VESA/Flush mount | l Transmittance | ≥85% |
| l Relative Humidity | 10 to 90% RH (non-condensing) | l Surface Hardness | 7H |
| l Vibration | 1.5Grms@5~500Hz, 0.15MM peak | ||
| l Shock | 10G, 11ms | ||
Display Panel
|
Model |
ITD-101CQ |
ITD-156CQ |
ITD-185CQ |
ITD-215CQ |
| Size | 10.1" | 15.6" | 18.5" | 21.5" |
| Resolution | 1280 x 800 | 1920*1080 | 1920*1080 | 1920*1080 |
| Aspect Ratio | 16:10 | 16:9 | 16:9 | 16:9 |
| Brightness | 500 cd/m2 | 400 cd/m2 | 300 cd/m2 | 250 cd/m2 |
| Contrast Ratio | 1300:1 | 1000:1 | 800:1 | 1300:1 |
| Number of Colors | 16.7M | 16.7M | 16.7M | 16.7M |
| Backlight Lifetime | 30000 hrs | 20000 hrs | 20000 hrs | 30000 hrs |
| Operating Temperature | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Storage Temperature | -20~70℃ | -20~70℃ | -20~70℃ | -20~70℃ |
| Product Weight | 1.04 kg | 2 kg | 2.96 kg | 6.5 kg |
| Product Dimensions(L*W*H) | 262.3*180.9*18 mm | 388.4*237.6*18 mm | 454.3*296.8*18 mm | 526.6*317.7*18 mm |
